Brief Look At Linux Traffic Control

Abstract

#

Traffic Control (TC) is one of those Linux subsystems that almost everyone has heard of, yet to many, including me, is a bit complicated and confusing.

Historically, TC was designed for traffic shaping, bandwidth control, queue management, etc. Today, however, it has grown into a much more flexible framework. With features such as packet classification, actions, and even eBPF integration, TC is capable of solving far more than just traffic shaping problems.

Although TC has existed for many years and is fairly documented, I often found myself jumping between man pages, kernel source, and blog posts before the pieces finally started to fit together. This article is an attempt to organize those pieces into the mental model which I hope will help clarify one of the most sophisticated parts of the Linux networking stack.

Where Does TC Live in the Networking Stack?

#

Before talking about TC-specific terms, it helps to understand where TC actually sits in the Linux’s networking stack.

The exact packet path inside the Linux kernel is much more involved than what I’ll show here, but for the purpose of understanding TC, we should be able to ignore many protocol-specific details.

On the egress side: (1) packets originate from an application and eventually make their way through the networking stack. After (2) routing and firewall decisions have been made, (3) packets arrive at TC. Once TC finishes processing them, they’re handed to the (4) NIC driver and (5) eventually transmitted on the wire.

On the ingress side, the process happens in reverse. Packets arrive from the NIC driver and are handed to TC before continuing further up the networking stack.

The important takeaway isn’t memorizing the packet path. It’s understanding why TC lives where it does. Since every packet passes through TC on both ingress and egress, it has an opportunity to inspect, classify, delay, redirect, or even drop packets before they continue their journey.

The Building Blocks of TC

#

One thing that confused me when I first started learning TC was that everyone immediately started talking about qdiscs, classes, filters, and actions. These building blocks are one of the reasons why TC is so flexible.

Qdisc: Who Decides When Packets Leave?

#

Imagine applications generating packets faster than the network can transmit them. Those packets have to wait somewhere (happens because CPUs are much faster than network interfaces).

That “somewhere” is managed by a queueing discipline, or qdisc.

Every network interface has at least one qdisc attached to it, even if you’ve never configured TC yourself. Linux automatically creates a default one for every interface.

At its core, a qdisc performs two simple operations:

• enqueue: accept a packet
• dequeue: decide when to release it

Everything else such as traffic shaping, bandwidth limiting, fairness, prioritization, congestion management, is ultimately built on top of these two.

A useful mental model is simply:

A qdisc decides when packets leave.

That may sound like a small responsibility, but by controlling when packets leave, a qdisc can smooth traffic bursts, enforce bandwidth limits, prioritize latency-sensitive traffic, or prevent one application from monopolizing the entire link.

Classes: What If Not All Traffic Is Equal?

#

Once you understand qdiscs, another question naturally appears.

What if not all traffic should be treated the same?

Perhaps you want SSH traffic to remain responsive while a large backup is running. Or maybe different containers should receive different bandwidth guarantees.

This is where classes come in.

One thing that tripped me up initially was thinking that a class was another queue. It isn’t.

Instead, you can think of a class as a traffic policy. A class describes things such as bandwidth guarantees, rate limits, priorities, and borrowing rules.

Classes only exist inside classful qdiscs, such as HTB or HFSC. These qdiscs support hierarchical scheduling, allowing multiple classes to coexist under a single qdisc. Each class can even have another qdisc attached beneath it, making it possible to build fairly flexible scheduling hierarchies.

The distinction that finally made sense to me was this:

Classes describe how traffic should be treated.
Qdiscs decide when packets are transmitted.

Filters: How Does TC Know Where Packets Belong?

#

Once multiple classes exist, another question immediately follows.

How does TC decide which packets belong to which class?

That’s the job of filters (also called classifiers). A filter examines packet metadata and decides where the packet should go.

packet
   │
   ▼
filter
   │
   ▼
class

TC provides several different classifiers, each suited to different workloads:

Actions: Actually Doing Something

#

Classification alone isn’t particularly interesting. Very often, matching a packet is only the beginning. Once a filter matches, we usually want to do something with that packet. That’s exactly what actions are for.

filter matches
        │
        ▼
     action

Some common actions include:

This is one of the reasons TC has become much more than a traffic shaping framework. By combining filters with actions, TC can implement packet mirroring, policy-based forwarding, traffic policing, encapsulation, and many other networking features.

At a Glance

#

Putting It Into Practice

#

Let’s put everything we’ve discussed together with a simple example.

Imagine a small office where employees are making VoIP calls while someone else is uploading a large backup. Without any traffic management, the backup can easily consume most of the available bandwidth. While both applications continue to work, the increased latency and jitter can noticeably affect call quality.

Our goal is simple:

prioritize VoIP traffic while still allowing the backup to use whatever bandwidth remains.

The first thing we need is a qdisc. Since packets may have to wait before they can be transmitted, something has to decide when they’re allowed onto the wire. That’s exactly the responsibility of the qdisc.

                Root qdisc

Next, we see that not all traffic should be treated equally. Voice packets deserve higher priority than a bulk file transfer, so we divide our traffic into separate classes.

                Root qdisc
               /          \
      VoIP Class      Best-effort Class

Of course, TC has no way of knowing which packets belong to each class on its own. That’s where filters come in. They inspect incoming packets and classify them into the appropriate traffic class.

            Incoming Packet
                    │
                    ▼
                 Filter
               /         \
      VoIP Packet     Backup Packet
           │                │
           ▼                ▼
     VoIP Class      Best-effort Class

Finally, we may want to perform additional processing once a packet has been classified. For example, we could police traffic that exceeds a certain rate, mirror packets for monitoring, or redirect them elsewhere. These operations are implemented as actions, allowing TC to do much more than simply decide where packets belong.

One interesting thing to notice is that we never configured a “VoIP scheduler” or a “backup scheduler.” Instead, we built our traffic policy by combining several independent building blocks. The qdisc decides when packets are transmitted, classes describe how different traffic should be treated, filters decide where packets belong, and actions define what happens to matching packets.

Our example also only uses a single level of classes, but that’s not a limitation of TC. Since classes can themselves have child qdiscs attached, the same building blocks can be used to build much larger traffic hierarchies.

                    Root qdisc
                         │
          ┌──────────────┴──────────────┐
          │                             │
     VoIP Class                 Best-effort Class
                                        │
                               Child qdisc
                                  │
                     ┌────────────┴────────────┐
                     │                         │
                  Web Traffic          Backup Traffic

This flexibility is one of TC’s greatest strengths. Rather than being a single traffic shaping algorithm, TC provides a framework for constructing packet processing pipelines, from simple policies like the one above to sophisticated hierarchical schedulers used in production networks.

Conclusion

#

TC is one of those Linux subsystems that initially feels far more complicated than it actually is. At first glance, the terminology alone can make it seem overwhelming. In reality, each concept has a well-defined responsibility, and the complexity comes from how these building blocks can be used together.

Rather than being a single traffic shaping algorithm, TC provides a flexible framework for building packet processing pipelines. Whether your goal is bandwidth management, packet scheduling, traffic classification, or packet manipulation, the same core concepts remain the foundation.

Thanks for reading, and see you in the next :)
